Model | Motor Gücü (P2) | Ürün Kodu | |
---|---|---|---|
kW | Hp | ||
WP 101 | 1,5 | 2 | 2851313 |
WP 102 | 2,2 | 3 | 2851314 |
WP 103 | 3 | 4 | 2851315 |
WP 104 | 4 | 5,5 | 2851316 |
WP 105 | 5,5 | 7,5 | 2851317 |
WP 107 | 7,5 | 10 | 2851318 |
WP 204 | 4 | 5,5 | 2851319 |
WP 205 | 5,5 | 7,5 | 2851320 |
WP 207 | 7,5 | 10 | 2851321 |
Model | Bağlantı Ölçüleri | A | F | H | H1 | H2 | N | N1 | W | S | Ağırlık (kg) |
|
---|---|---|---|---|---|---|---|---|---|---|---|---|
DN1 | DN2 | (mm) | ||||||||||
WP101 | 1 1/4" | 1" | 84 | 405 | 263 | 110 | 153 | 225 | 185 | 26 | 11 | 24,1 |
WP102 | 1 1/2" | 1" | 86 | 407 | 263 | 110 | 153 | 225 | 185 | 26 | 11 | 26,1 |
WP103 | 1 1/2" | 1 1/4" | 95 | 464 | 304 | 132 | 172 | 266 | 206 | 19 | 14 | 39,1 |
WP104 | 1 1/2" | 1 1/4" | 95 | 464 | 304 | 132 | 172 | 266 | 206 | 19 | 14 | 42,9 |
WP105 | 2" | 1 1/4" | 95 | 542 | 304 | 132 | 172 | 266 | 206 | 19 | 14 | 56 |
WP107 | 2" | 1 1/4" | 95 | 542 | 304 | 132 | 172 | 266 | 206 | 19 | 14 | 61,7 |
WP204 | 2" | 1 1/2" | 108 | 496 | 334 | 139 | 195 | 292 | 232 | 21 | 14 | 49,8 |
WP205 | 2" | 1 1/2" | 108 | 542 | 334 | 139 | 195 | 292 | 232 | 21 | 14 | 55,1 |
WP207 | 2" | 1 1/2" | 108 | 542 | 334 | 139 | 195 | 292 | 232 | 21 | 14 | 60,8 |
